JAYLEC - Aftermarket Land Cruiser 1FZ 165MM CTR - CTR FZJ105R 12V 110A Alternator

JAYLEC - Landcruiser 1FZ 165MM CTR - CTR FZJ105R 12V 110A Alternator - Suits Toyota

BRAND NEW - JAYLEC Branded

Specifications:
Adj. Hole Diameter: -
Adj. Pivot 160mm
Inside Foot to Foot: -
Pivot Hole Diameter: 1 x 10mm
Pivot Lug Length: 58mm
Voltage: 12V
Amperage: 100A
Mount Leg ID: 58mm
C-C Mounts: 165mm
Hole ID Top: M8
Hole ID Bottom: 10mm
Shaft Size: -
Pulley Type: TWIN "A"
Pulley Belt Width: -
Pulley Grooves: 2
Pulley diameter: 74mm
Regulator Type: INTERNAL
Series: -
Connections Plug #: EP24
Terminals: B+-S-IG-L
Excitation: EXTERNAL
Ground: NEGATIVE
Weight (Kg): 7.0kg

Standard 12 Month Warranty

Buy an internationally known and branded product that you can rest assured is quality, not some unbranded, unknown gear!

Please check pictures against your current alternator to avoid disappointment as we can't take returns of electrical parts that are incorrect.  If you need to check fitment, please contact us with your vehicle make, model, year, transmission and / or license plate (if road registered in New Zealand).
